HD-9ST | 4-Post Hoist

SKU: 5175860

A slim, powerful, and ALI-certified four-post hoist, designed for compact spaces without sacrificing performance. With a 4,082-kg lifting capacity, adjustable lock ladders, and a freestanding design, the HD-9ST is ideal for both home garages and professional workshops.

4,082-kg lifting capacity
Narrow width for space efficiency
Adjustable safety lock system
Hydraulic/electric power system
Optional accessories available for customization
ALI-certified for safety and reliability

Here to help

Features

A narrow four-post hoist built for garages or workshops with limited space, offering a slim footprint while maintaining full lifting capability.

Heavy-Duty Lifting Power
Capable of lifting up to 4,082 kg, supporting both standard and narrow vehicles with ease.

Certified Safety & Reliability
Meets or exceeds CE and ALI safety standards, ensuring professional-grade durability.

Adjustable Locking System
Multi-position safety locks provide enhanced security at different lift heights.

Fully Enclosed Cables & Sheaves
Ensures smooth and safe operation with reduced wear and tear over time.

Freestanding & Space-Saving
No floor anchors required, making it flexible for various workshop configurations.

Optional Drive-Thru Ramps
Customisable with drive-thru ramps, solid deck, and rolling jacks for added functionality.

Materials & Tech

Manufactured with high-strength steel, featuring a hydraulic lifting system and oversized self-lubricating cable rollers for long-lasting performance.

HD-9ST Four-Post Hoist
Hydraulic power unit
Adjustable safety locks
Removable approach ramps

Optional

2,041-kg air/hydraulic rolling jacks (Model RJ-45)
Drip trays for fluid management
Solid deck for increased storage capacity

Specifications

CAPACITY	Imperial	Metric
Lifting Capacity	9,000 lbs	4,082 kg
Max Capacity / Front Axle	4,500 lbs	2,041 kg
Max Capacity / Rear Axle	4,500 lbs	2,041 kg

RISE	Imperial	Metric
A – Min. Runway Height	4.5″	114 mm
B – Max. Rise	70″	1,778 mm
C – Max. Lifting Height	74.5″	1,892 mm
Time to Full Rise	45 seconds	–

OUTSIDE DIMENSIONS	Imperial	Metric
D – Overall Width	100.25″	2,546 mm
E – Outside Length	174″	4,420 mm
F – Overall Length	200″	5,080 mm
G – Height of Columns	88″	2,235 mm

INSIDE DIMENSIONS	Imperial	Metric
H – Width Between Columns	89.75″	2,280 mm
I – Drive-Thru Clearance	76.5″	1,943 mm

RUNWAYS	Imperial	Metric
J – Runway Width	19″	483 mm
K – Length of Runways	164″	4,166 mm
L – Width Between Runways	37.5″	953 mm
M – Runway Centerline	56.5″	1,435 mm
N – Outside Edge of Runways	75.5″	1,918 mm

MINIMUM WHEELBASE	Imperial	Metric
Rated Capacity	115″	2,921 mm
75% Capacity	100″	2,540 mm
50% Capacity	85″	2,159 mm
25% Capacity	70″	1,778 mm

LOCKING	Imperial	Metric
Locking Positions	12	–
