SKU: 5175427
The BendPak PL-6000DC is a versatile two-post parking lift with a 6,000-lb. capacity, designed for compact parking solutions. Featuring a shared column design, this lift allows multiple units to be installed in close proximity, maximizing parking density in commercial and residential spaces. Built for indoor and outdoor applications, the PL-6000DC is the ideal solution for real estate developers, automotive dealerships, and commercial parking facilities
PL-6000DC
Features
Heavy-Duty Hydraulic Drive System
A single direct-drive hydraulic cylinder eliminates complex screw mechanisms, enhancing reliability and reducing maintenance.
Automatic Safety Locks & Anti-Fall Protection
Features built-in locking mechanisms and anti-fall safety devices, preventing sudden platform drops in case of system failure.
Low Operating Costs & Energy Efficiency
The platform is gravity-driven when lowered, requiring zero electric motor consumption, reducing operational costs.
Freestanding Design for Versatile Installation
The rugged steel frame is engineered for installation on standard parking surfaces, allowing for indoor and outdoor use.
Professional Packing & Quick Installation
The PL-6000DC arrives with a detailed installation manual, foundation drawings, and online video support for quick setup.
Materials & Tech
Optional
| Total Lifting Capacity | 6,000 lbs. (2,722 kg) |
| Ganged Column Design | Yes |
| Lifting Time | 50 sec. |
| Specification | Details |
| Total Width | 2,547 mm (100.25″) |
| Total Length | 4,250 mm (167.25″) |
| Overall Height | 3,327 mm (131″) |
| Lifting Height | 2,100 mm (82.5″) |
| Platform Width | 2,100 mm (82.5″) |
| Platform Length | 3,990 mm (157″) |
| Drive-Thru Width | TBD |
| Specification | Details |
| Corrugated, Anti-Slip Surface | Yes |
| Locking Positions | Every 4 inches |
| Specification | Details |
| Automatic Locking System | Yes |
| Emergency Stop Button | Yes |
| Upper Limit Switch for Safety | Yes |
| Specification | Details |
| Power Unit | 2.2 kW Hydraulic Power Pump |
| Motor Options | 110V or 220V AC / 50-60 Hz / 1 or 3 Phase |
| Control Power | 24V AC |
| Noise Level | TBD |
| Specification | Details |
| Shipping Weight | TBD |
| Shipping Dimensions | TBD |
