Diamond 70/2-Piston

SKU: DIAMOND-70-2P

The Stertil-Koni Diamond 70/2-Piston is a premium in-ground piston lift designed for heavy-duty vehicle maintenance. Featuring a lifting capacity of 70,000 lbs. (35,000 lbs. per piston), this flexible system ensures maximum safety, efficiency, and durability. With ebright Smart Control System and biodegradable hydraulic technology, it’s an eco-friendly, high-performance lifting solution.

70,000 lbs. lifting capacity (35,000 lbs. per piston)
73-inch lifting height for superior accessibility
Continuous Recess™ option for low-clearance vehicles
Ebright Smart Control System with a 7-inch touchscreen
Hydraulic system with self-cleaning surfaces
Environmentally friendly with biodegradable oil

Here to help

Diamond 70/2-Piston

Features

The Diamond 70/2-Piston provides industry-leading lifting power with advanced hydraulic technology, ensuring smooth, synchronized lifting for heavy commercial vehicles. Its in-ground design makes it ideal for maximizing workshop space.

Industry-Leading Safety

Gravity-Engaged Locking System: 3-inch increments with 21 locking positions for precise control.
Independent Mechanical Locking System: Engages at 8.5 inches of rise, ensuring full vehicle support.
Solid 3-inch Steel Locking Rods: Hardened, nitrated finish for corrosion resistance.
Automatic Wheel Base Positioning (AWBP): Enables easy preset configurations for faster lift setup.

Ebright Smart Control System

7-inch full-color touchscreen for intuitive operation.
Multi-language support and user-configurable settings.
Customizable user ID key to prevent unauthorized operation.
Real-time piston synchronization for safe and smooth lifting.

Eco-Friendly & Durable Construction

Biodegradable oil system reduces environmental impact.
Hot-dip galvanized foundation components for corrosion resistance.
DiamondGuard® coating prevents electrolysis & hazardous fluid damage.
Self-cleaning hydraulic horizontal drive system minimizes wear and tear.

Enhanced Workshop Efficiency

Adapters for various vehicle types (flip-up, differential, landing gear).
Pit covers with a skid-resistant surface, supporting up to 13,500 lbs. of wheel load.
Remote control option for added flexibility and safety.

Materials & Tech

The Diamond 70/2-Piston features high-quality hydraulic cylinders, hard-chrome plated pistons, and synthetic support slides instead of steel rollers, ensuring minimal wear, high load distribution, and extended lifespan.

Inclusions

Pre-configured lift system
Standard lifting adapters (various configurations)
Aluminum shutter-style pit covers
Ebright Smart Control System

Optional

Continuous Recess™ system for low-clearance vehicles
Additional vehicle adapters for specialized applications
Remote control for added convenience
Integrated sump pumps for liquid evacuation

Specifications

GENERAL SPECIFICATIONS
Lifting Capacity	70,000 lbs. (35,000 lbs. per piston)
Lifting Height	73 inches
Pit Depth	69 inches
Minimum Wheelbase	48 inches
Lifting/Lowering Time	90 seconds

HYDRAULIC & ELECTRICAL
Hydraulic System	High-pressure system with biodegradable oil
Motor Power	2 x 5 HP
Compressed Air Supply	5 CFM @ 60 PSI
Electrical Supply	3-phase, 208-230/460/575 Volt

CONFIGURATION OPTIONS
Frame Version	Variable travel range from 10 to 19 feet
Cassette Version	Available in 10 ft, 13 ft, or 17 ft travel ranges

Brand Spotlight

StertilKoni

Stertil-Koni is a global leader in heavy-duty vehicle lifts, known for its unmatched quality, innovation, and reliability.

Exclusively supplied in Australia by Genesis Equipment, Stertil-Koni products stand out with patented technologies such as wireless mobile column lifts, the innovative EARTHLIFT energy retrieval system, and microprocessor-controlled lifting systems. These features ensure exceptional safety, efficiency, and durability, making Stertil-Koni the trusted choice for heavy-duty lifting. With Genesis Equipment’s industry expertise and after-sales support, Stertil-Koni continues to set the benchmark for excellence in the Australian market.

Other StertilKoni Products

Ranger

Tyre Inflation Cage

— Wheel Service Equipment

BendPak

Litestix Under Hood Work Light

— Workshop Equipment

Nussbaum

Top Lift 2.35 TLD XY

— Vehicle Lifts

Product Uses

What some of our customers have used it for:

No data was found

Perfect for:

Heavy-duty commercial workshops
Municipal fleet maintenance
Logistics & freight carriers
Mining & industrial vehicle servicing
Public transportation garages
Large truck & bus repair centers
