SKU: 5175154
The BendPak PL-6KT is a high-capacity triple-wide parking lift designed to transform a three-car garage into a six-car powerhouse. With independent platforms and a streamlined four-column design, this lift eliminates the need for multiple hoists while ensuring easy vehicle access and optimal space efficiency. Perfect for residential garages, commercial spaces, and municipal parking solutions.
Features
Independent Platform Operation
Each of the three platforms lifts independently, eliminating the need to move lower vehicles when accessing the upper decks.
Heavy-Duty Hydraulic & Steel Construction
Built with rugged I-beam and C-channel steel and dual hydraulic cylinders for superior lifting power and stability.
Auto-Locking Safety Mechanism
A single-position, auto-engaging safety lock ensures maximum security when storing vehicles long-term.
Internally Routed Hydraulic & Cable Systems
All hydraulic lines and cables are internally routed for a sleek, safe, and efficient lifting process.
Customisable Power Options
Operates on 240V (1 Ph) or 240V, 380V, 460V (3 Ph) power, with international voltage options available.
Materials & Tech
Optional
| Specification | Details |
| Total Lifting Capacity | 8,165 kg (2,722 kg per deck) |
| Independent Platforms | Yes |
| Lifting Time | 30 seconds |
| Specification | Details |
| Total Width | 7,834 mm (308″) |
| Total Length | 6,008 mm (236.5″) |
| Overall Height | 3,140 mm (123.75″) |
| Width Between Posts | 7,197 mm (283″) |
| Drive Clearance | 2,374 mm (93″) |
| Specification | Details |
| Platform Width | 2,086 mm (82″) |
| Platform Length | 3,862 mm (152″) |
| Min. Runway Height | 230 mm (9″) |
| Max. Rise | 2,261 mm (89″) |
| Specification | Details |
| Safety Lock Positions | 1 |
| Heavy-Duty Aircraft Cable | 10 mm |
| Specification | Details |
| Motor | 220V AC / 60 Hz / 1 Ph |
| Noise Level | TBD |
| Specification | Details |
| Shipping Weight | TBD |
| Shipping Dimensions | TBD |
